Low power long range sx1276 data LoRa Bee 868MHz

FOB Reference Price:Get Latest Price
$5.00 - $10.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Model Number:
LoRa.House V1.0.0, Lora.house
Place of Origin:
Guangdong, China, Guangdong, China (Mainland)
Brand:
Oolite
OEM/ODM:
enable
Size:
16.8*32.3mm
OEM:
enable
High sensitivity:
down to -148 dBm
Bullet-proof front end::
IIP3 = -12.5 dBm
Low RX:
10.3 mA, 200 nA register retention
Temperature:
built-in temperature sensor and low battery indicator
Brand Name:
Oolite
Supply Ability
Supply Ability:
5000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
Carton case
Port
shenzhen
Lead Time :
20-25 working days
Product Description
Best quality lora house wifi router

        The Lora.House V1.0 transceivers feature the LoRa TM long range modem that provides ultra-long range spread spectrum communication and high interference immunity whilst minimising current consumption. Using Hope RF‟s patented LoRa TM modulation technique RFM95/96/97/98 can achieve a sensitivity of over -148dBm using a low cost crystal and bill of materials. The high sensitivity combined with the integrated +20 dBm power amplifier yields industry leading link budget making it optimal for any application requiring range or robustness. LoRa TM also provides significant advantages in both blocking and selectivity over conventional modulation techniques, solving the traditional design compromise between range,interference immunity and energy consumption.

       These devices also support high performance (G)FSK modes for systems including WMBus, IEEE802.15.4g. The Lora.House V1.0 deliver exceptional phase noise, selectivity, receiver linearity and IIP3 for significantly lower current consumption than competing devices
Detailed Images

Features:

   LoRa TM Modem (868Mhz).


 168 dB maximum link budget.

 +27 dBm +- 1dbm constant RF output vs. V supply.

 +20 dBm high efficiency PA - RFX1010.

 Programmable bit rate up to 300 kbps.

 High sensitivity: down to -148 dBm.

 Bullet-proof front end: IIP3 = -12.5 dBm.

 Excellent blocking immunity.

 Low RX current of 10.3 mA, 200 nA register retention.

 Fully integrated synthesizer with a resolution of 61 Hz.

 FSK, GFSK, MSK, GMSK, LoRaTM and OOK modulation.

 Built-in bit synchronizer for clock recovery.

 Preamble detection.

 127 dB Dynamic Range RSSI.

 Automatic RF Sense and CAD with ultra-fast AFC.

 Packet engine up to 256 bytes with CRC.

 Built-in temperature sensor and low battery indicator.

 Modue Size:16.8*32.3mm


APPLICATIONS:

 Automated Meter Reading.

 Home and Building Automation.

 Wireless Alarm and Security Systems.

 Industrial Monitoring and Control

 Long range Irrigation Systems


Pins:

Our Company

Shenzhen Gainstrong Technology Ltd. is a professional manufacturer for Network communication products ,including wifi Routers,wifi modules, Industial wifi equipment,smart home devices...and so on .The company was established on 2009 ,Our factory located in Shajing town ,Bao An District ,Shenzhen, China ,We are focus on ODM and OEM service to the customer all over the world with professional R&D team . Factory equipped with sophisticated manufacturing machines ,include 1 High-speed SMT production lines and 2 product-assembly lines, about 40 staff, Production capacity for wifi modules can be 2000pcs per day.
With professional mind, we are trying to offer the customer the most competive price ,quick lead time for delivery, strict quality inspection and intimate customer servervice. To satisfy customer perfectly,we are managing the safety ability and the design which combines the sensibility and technique , as well as the advanced equipment.

Certifications
FAQ

1. Can I take a sample before bulk order?
Yes, we can support you samples for function test first.

2. How long to make sample or mass production?
Usually we have sample in stock, processing time will be around 3~5days

3. Do you accept OEM / OEM?
GainStrong is engaged in providing professional ODM/OEM service of customized electronic productions. Our R&D team members have rich hardware and software experience on providing global customers with complete stable and cost-effective products.

4. Is there MOQ limit?
Welcome to place sample order to check the quality before bulk orders.
Any qty welcome,but as you know,different qty with different price.
Large qty means low cost.
