best 4g mini pcie mt7620 embedded usb wifi module iot module ropenwrt module

FOB Reference Price:Get Latest Price
$7.80 - $15.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Model Number:
Oolite - MT7620A
Brand Name:
Oolite
Place of Origin:
Guangdong, China
Chipset:
MT7620A
RAM:
256M (64/128/256M option)
SPI flash):
16M (4 /8/16/32/64M option)
PCIe:
1
USB:
USB2.0
SDHC:
1
UART:
2
PCM&I2S:
1
Power supply voltage:
3.3V
Dimensions:
40 * 40MM
Supply Ability
Supply Ability:
3000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
plastic bag or other
Port
shenzhen
Lead Time :
3 weeks
Product Description

1 Introduction

This document describes the detailed Hardware specifications of Our WIFI Core

Module.

This document designed for R&D department, Service Operator, System Operator,

technical support, engineering services.

2 Overview of Hardware Specification requirements


Detailed Images

4 Pin Description

Pin Out Name Description

1 ND_GND

These pin shared with Nand and SD interface

2 ND_WP/SD_WP

3 ND_RB_N/SD_CLK

4 ND_CLE/SD_CD

5 ND_ALE/SD_CMD

6 ND_D7/BT_ANT

7 ND_D6/BT_WACT

8 ND_D5/BT_AUX

9 ND_D4/BT_STAT

10 ND_D3/SD_D3

11 ND_D2/SD_D2

12 ND_D1/SD_D1

13 ND_D0/SD_D0

14 TXD Uart Full

15 RXD

16 DSR_N

17 DCD_N

18 DTR_N

19 RIN

20 CTS_N

21 RTS_N

22 UART_3.3V

Uart Lite

23 UART_TXD2

24 UART_RXD2

25 UART_GND

26 I2C_GND

27 I2C_SCLK I2C

28 I2C_SD


Our Company

Shenzhen Gainstrong Technology Ltd. is a professional manufacturer for Network communication products ,including wifi Routers,wifi modules, Industial wifi equipment,smart home devices...and so on .The company was established on 2009 ,Our factory located in Shajing town ,Bao An District ,Shenzhen, China ,We are focus on ODM and OEM service to the customer all over the world with professional R&D team . Factory equipped with sophisticated manufacturing machines ,include 1 High-speed SMT production lines and 2 product-assembly lines, about 40 staff, Production capacity for wifi modules can be 2000pcs per day.


With professional mind, we are trying to offer the customer the most competive price ,quick lead time for delivery, strict quality inspection and intimate customer servervice. To satisfy customer perfectly,we are managing the safety ability and the design which combines the sensibility and technique , as well as the advanced equipment.


FAQ

1. Can I order a sample ? how fast can l get it ?
Yes, usually we have sample in stock, even without, processing time will be around 3~4days

2.. How fast can l get my order after paid?
Our processing time from 1-4 business days, according to size and quantity, and shipping way
Usually, for sample order we ship out in 3-5days , delivery time is around 20~25days

3.Do you support Logo ordering? what is the mini order quantity?
Yes, we provide logo ordering for customers who purchase at least 1000 dollars.
If the assume doesn’t reach 1000 dollars, we need to ask about 1000RMB for design cost.

GainStrong is engaged in providing professional ODM/OEM service of customized electronic productions. Our R&Dteam members have rich hardware and software experience on providing global customers with complete stable andcost-effective products.
