The IPQ4019 is a highly integrated system-on-chip (SoC) designed for high-performance, powerefficient, and cost-effective 2×2, 802.11ac, dual-band concurrent access-point applications. The SoC incorporates a quad-core ARM Cortex A7 processor, two dual-band, concurrent 802.11ac Wave-2 Wi-Fi subsystems, and a five-port Gigabit Ethernet Layer2/3/4 multilayer switch supporting line rate network address translation (NAT). It supports one USB3.0 and one USB2.0. It also supports miscellaneous interfaces such as I2S, SPDIF, I2C, SMI, UART, JTAG, etc., which can be configured as general purpose I/O pins. The block diagram in Figure1-1 shows the major components of the SoC.
CPU nominal frequency
CPU core count
Number of USB ports
Supported input voltage
DC: 12V/2A; POE: 802.3 at POE+ 48V/0.5A
Max power consumption
280 mm×166 mm×24mm
USB slot type
1x SD card
Operation Temperature: -10oC to +50oC
-40oC to +70oC
Radio I: 11b/g/n: 2.412~2.484 GHz
OFDM: BPSK, QPSK, 16-QAM, 64-QAM
Radio II: 11a/n: 5.18~5.24 & 5.26~5.32 & 5.5~5.7 &
OFDM: BPSK, QPSK, 16-QAM, 64-QAM, 256-QAM
5G, Country Dependent
Shenzhen Gainstrong Technology Ltd. is a professional manufacturer for Network communication products ,including wifi Routers,wifi modules, Industial wifi equipment,smart home devices...and so on .The company was established on 2009 ,Our factory located in Shajing town ,Bao An District ,Shenzhen, China ,We are focus on ODM and OEM service to the customer all over the world with professional R&D team . Factory equipped with sophisticated manufacturing machines ,include 1 High-speed SMT production lines and 2 product-assembly lines, about 40 staff, Production capacity for wifi modules can be 2000pcs per day.
With professional mind, we are trying to offer the customer the most competive price ,quick lead time for delivery, strict quality inspection and intimate customer servervice. To satisfy customer perfectly,we are managing the safety ability and the design which combines the sensibility and technique , as well as the advanced equipment.
1. Can I order a sample ? how fast can l get it ? Yes, usually we have sample in stock, even without, processing time will be around 3~4days 2.. How fast can l get my order after paid? Our processing time from 1-4 business days, according to size and quantity, and shipping way Usually, for sample order we ship out in 3-5days , delivery time is around 20~25days 3.Do you support Logo ordering? what is the mini order quantity? Yes, we provide logo ordering for customers who purchase at least 1000 dollars. If the assume doesn’t reach 1000 dollars, we need to ask about 1000RMB for design cost.
GainStrong is engaged in providing professional ODM/OEM service of customized electronic productions. Our R&D team members have rich hardware and software experience on providing global customers with complete stable and cost-effective products.
