Powerful 802.11n Openwrt wifi module

FOB Reference Price:Get Latest Price
$9.40 - $18.00 / Piece | 1 Piece/Pieces (Min. Order)
Support Sea freight
Report Suspicious Activity
Quick Details
Model Number:
Oolite V5
Brand Name:
Place of Origin:
Guangdong, China
Model Numbe:
Oolite V5R V1.0
256MB DDR1(128MB optional
CPU frequency:
550 MHz
USB 2.0,1 WAN, 4 LAN, 1 PCIE
2 external antenna
16MB SPI NOR Flash(8/16/32/64M option)
Wireless speed:
144 Mbps for 20 MHz and 300 Mbps for 40 MHz
27.5 * 51.4MM +- 0.1mm
Supply Ability
Supply Ability:
5000 Piece/Pieces per Day
Packaging & Delivery
Packaging Details
plastic tray or blister
Lead Time :
15-20 working days after payment
Product Description

Powerful 802.11n Openwrt wifi module

The Oolite V5R is a complete,small 802.11a/b/g/n Wi-Fi Solution optimized for low-cost, and highly integrated AP and consumer electronic devices,the module integrates all Wi-Fi functionality in a package friendly to low-cost PCB design, requiring only a 3.3V power supply .
The module based on the QCA9531 which integrates an 802.11n 2x2. MIMO MAC/BB/ radio with external PA and LNA. It supports 802.11 n operations up to 144 Mbps for 20 MHz and 300 Mbps for 40 MHz, compatible 802.11b/g/n.
The module support AP mode, client mode at the same time , and include mass service application software to reduce the research and design work of customer.

Applications Stage
● Smart home network equipment
● Wireless WIFI device, unmanned aerial vehicle
● Dual band Router, Industry Controller and so

product details

1.  Characteristics:
◆ CPU: QCA9531 with 550 MHz MIPS 24Kc
◆ RAM: 256MB DDR1 RAM (128MB optional)
◆ Flash: 16MB SPI NOR Flash(8/16/32/64M option)
◆ Wireless speed: 144 Mbps for 20 MHz and 300 Mbps for 40 MHz
◆ USB: USB 2.0 master interface
◆ Power supply voltage: 3.3V
◆ Port: 1WAN+ 4 LAN
◆ GPIO:17
◆ Antenna:2×external antenna.
◆ 25 MHz reference clock input
◆ 1.2 V switching regulator
◆ Advanced power management with dynamic clock switching for ultra-low power modes

The general Hardware architecture is shown below Figure:

Pin Description.

The OoliteV5R has 67 pins , including x1 PCIE channel*1, USB2.0*1, JTAG*1,UART*1, 1WAN AND 4 LAN Ethernet ports, and many GPIOs.




Our Company

Shenzhen Gainstrong Technology Ltd. is a professional manufacturer for Network communication products ,including wifi Routers,wifi modules, Industial wifi equipment,smart home devices...and so on .The company was established on 2009 ,Our factory located in Shajing town ,Bao An District ,Shenzhen, China ,We are focus on ODM and OEM service to the customer all over the world with professional R&D team . Factory equipped with sophisticated manufacturing machines ,include 1 High-speed SMT production lines and 2 product-assembly lines, about 40 staff, Production capacity for wifi modules can be 2000pcs per day.
With professional mind, we are trying to offer the customer the most competive price ,quick lead time for delivery, strict quality inspection and intimate customer servervice. To satisfy customer perfectly,we are managing the safety ability and the design which combines the sensibility and technique , as well as the advanced equipment.

Our Service

We can flash customer firmware, ODM and OEM are both supported  !we can make sure device fit FCC,CE and so on. we can supply software design service !

Packing & Delivery


Packaging Details:

Powerful 5km 802.11n Openwrt WIFI Gateway Router Gigabit  plastic tray or blister
Delivery Detail:

Powerful 5km 802.11n Openwrt WIFI Gateway Router Gigabit  3-5days or 15-25 working days


1.Can we get a lower price? Any Discount?
Yes,price is not a problem,everything could be negotiated based on the quantity.

2.OEM,ODM Service is available?
Yes, GAINSTRONG have strong ability to offer customers ODM&OEM products of highest quality.
And it will requirement about your quantity.

3.For Trade Terms,such as payment and leadtime.
>Payment Terms:We mainly support T/T bank transfer,Paypal and Western Union
>Price Terms:FOB Guangzhou
>Shipping Methods: EMS,DHL,Fedex,TNT,UPS,by sea or your own shipping agent
>Leadtime: Sample order,3-7work days; Bulk order 15-25work days(after your payment )
